| 10/100 Port | Yok |
| Kasa Tipi | Masaüstü Plastik Kasa |
| UPLINK / Bakır | Yok |
| Combo Özelliği | Yok |
| Poe Özelliği | Yok |
| Yönetilebilirlik | Yok |
| SFP Girişi / UPLINK | Yok |
| Toplam Port Sayısı | 5 |
| GIGABIT Port Sayısı | 5 |
| Açıklama | Genel Özellikler Fiziksel Özellikler Interfaces 5 Gigabit Ethernet ports 10/100/1000 Base-T Supported Features • Green Ethernet • Switch fabric: 10 Gbit / s • Automatic polarity of MDI / MDIX on all ports • Switching Method: store-and-forward • Ethernet / Fast Ethernet: full duplex / half duplex • IEEE 802.3x Flow Control • Jumbo-frames 9216 bytes • Supports IEEE 802.1p QoS (4 queues, Strict Mode) • Cable Diagnostics Standards • IEEE 802.3 10BASE-T Ethernet (twisted-pair copper) • IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper) • IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted-pair copper) • ANSI / IEEE 802.3 NWay auto-negotiation of speed and mode • IEEE 802.3x Flow Control • IEEE 802.3az Energy-Efficient Ethernet (EEE) Protocol CSMA / CD Data rate • Ethernet: 10 Mbit / s (half duplex) 20 Mbit / s (full duplex) • Fast Ethernet: 100 Mbit / s (half duplex) 200 Mbit / s (full duplex) • Gigabit Ethernet: 2000 Mbit / s (full duplex) Switching Method Store-and-forward Table MAC-addresses K 2 Study of MAC-addresses Automatic updates Speed ??Packet Filtering / Forwarding • Ethernet: 14,880 packets / second per port • Fast Ethernet: 148,800 packets / second per port • Gigabit Ethernet: 1488000 packets / second per port Buffer RAM 128 KB per unit Indicators • Per port: Link / Activity / Speed • On the device: Power Interfaces transmission medium Automatic determination of the polarity of MDI / MDIX on all ports Fiziksel Özellikler Measurements 91 x 73 x 22 mm Weight 330 g Nutrition Power adapter 5V/1A Power consumption Input: 2.37 W DC, AC 3.9 W Temperature • Operating: 0 º to 40 º C • Storage: -10 to 70 ° C Humidity • Operating: 10% to 90% (non-condensing) • Storage: 5% to 90% (non-condensing) MTBF 1261786.896 hours Certifications • CE class B • FCC class B • ICES-003 Class B • VCCI class B • C-Tick • Anatel • CCC • cUL • CB • LVD |
